Can you edit or reset the pulse value of the S0/M 4?
No, it is an unalterable counter.
S0/M-F 4
Description
4-channel impulse counter for counting impulses that are generated by energy counters via reed contacts or passive transistor outputs (open collectors) in proportion to the energy measured. Impulses of any potential-free contacts can be recorded for counting, for example, events up to a frequency of 15 Hz. The impulses generated by the energy counters are recorded by means of a standardized current interface to DIN EN 62053-31 class A. The 4-channel impulse counter occupies a clear M-Bus address specified by the manufacturer. Suitable for decentralized mounting on DIN TH35 rail according to IEC 60715 in electrical distribution cabinets.
- Connection with spring clamp terminal blocks (push-in)
Technical Data
General Data
M-Bus
Two-wire bus
300 bit/s, 2400 bit/s and 9600 bit/s
24 V DC +/- 10 % (SELV)
50 mA DC
4 x S0 according to DIN EN 62053-31 Class A
green LED flashes at incoming pulse
50 x 69.3 x 60 mm
approx. 70 g
-10 °C to 50 °C
-20 °C to 70 °C
IP40 / IP20
Check US distributor inventory
Accessories
Accessory of
Part number
11055670
4251394620916
Downloads
- Brochure (Data logger)
- 3D-Data - Registration required -
- Mounting note (110556, 11055670)
- Mounting note (Safety Instructions multilingual )
- Data sheet
FAQ's
Additional Information
