BMT-SI4 BACnet MS/TP
The BACnet MS/TP module with 4 S0 inputs according to DIN EN 62053-31 class A was developed for decentralized switching tasks. It is suitable, among other things, for counting S0 counter pulses. This allows very good integration of the module into an energy controlling system. In case of a power failure, the last counter readings are saved. The inputs can be scanned by means of standard objects via a BACnet client. When using the Accumulator Object, pulses up to 50 Hz can be counted, when using the PulseConverter object, pulses up to 500 Hz can be counted. Module address and bit rate are set with two rotary switches on the front. Suitable for decentralized mounting on DIN TH35 rail according to IEC 60715 in electrical distribution cabinets.
- Connection with screw type terminal blocks
- Data sheet
- ePLAN data - Registration required -
- Brochure (Intelligent system components with integrated application software)
- Brochure (BACnet MS/TP components)
- Brochure (BACnet Router)
- REACh Statement
- 3D-Data - Registration required -
- Product information
- Software (BACnet EDE-Files)
- Mounting note (11088913, 1108891370)
- Mounting note (Safety Instructions multilingual )
- Software manual
