LF-DI10-IP65 LON
Description
The LON module in an IP65 housing with 10 digital inputs was developed for decentralized switching tasks. It is suitable for detecting potential-free switch states, for example electrical limit switches on vent valves or auxiliary contacts of power contactors. The inputs can be used as contact or voltage inputs and scanned individually or simultaneously by SNVT network variables.Suitable for decentralized mounting in serial sub-distributor.
Technical Data
General Data
TP/FT-10, free topology
FT5000
78 KBit/s
24 V AC/DC +/- 10% (SELV)
63 mA (AC) / 21 mA (DC)
100 %
550 ms
10 x contact or voltage
30 V AC/DC
more than 8 V AC/DC
Green and yellow LED
160 x 40.7 x 120 mm
300 g
-5 °C to 55 °C
-20 °C to 70 °C
IP65 / IP20
Check US distributor inventory
Accessories
Part number
1108511319IP
4250184135708
