LF-AOP4 LON
Description
The LON module with 4 analog outputs was developed for decentralized switching tasks. It is suitable as encoder for control variables, for example for electrical vent and mixing valves, valve positions, etc. The analog outputs can be activated proportionally by SNVT network variables, or previously defined voltage values can be adjusted. Each output can be set for automatic or manual operation by means of 4 potentiometers at the front. Suitable for decentralized mounting on DIN TH35 rail according to IEC 60715 in electrical distribution cabinets.
- Connection with screw type terminal blocks
Technical Data
General Data
TP/FT-10, free topology
FT5000
78 KBit/s
24 V AC/DC +/- 10 % (SELV)
100 mA (AC) / 40 mA (DC)
100 %
550 ms
4 x analog
0 V to 10 V DC
5 mA at 10 V DC
0.3125 mV/digit
100 mV
Green and yellow LED
35 x 69.3 x 60 mm
84 g
-5 °C to 55 °C
-20 °C to 70 °C
IP40 / IP20
Check US distributor inventory
Accessories
Part number
11085413
4250184135746
Downloads
- Data sheet
- ePLAN data - Registration required -
- Brochure (LON I/O components)
- Brochure (Intelligent system components with integrated application software)
- 3D-Data - Registration required -
- Software (Template_LF-AOP)
- Software (LON Resource Files 1.32)
- Software (METZ Connect PlugIn LF-ALL 2.0.0)
- Mounting note (11085413, 1108541370 )
- Mounting note (Safety Instructions multilingual )
- Software manual
