LF-F-CI4 LON
Description
The LON module with analog inputs was developed for decentralized switching tasks. It is suitable for detecting 4 currents and 4 voltages of, for example, active temperature sensors, electrical vent and mixing valves, valve positions, etc. The inputs can be scanned by SNVT network variables. Suitable for decentralized mounting on TH35 rails according to IEC 60715 in electrical distribution cabinets.
- Connection with spring clamp terminal blocks (push-in)
Technical Data
General Data
TP/FT-10, free topology
FT5000
78 KBit/s
24 V AC/DC +/- 10 % (SELV)
67 mA (AC) / 24 mA (DC)
100 %
550 ms
4 x voltage, 4 x current
0 V to 10 V DC
10 mV (0 to 100 %)
10 kOhm
0 to 20 mA DC
0.05 mA
1 %
Green and yellow LED
35 x 69.3 x 60 mm
84 g
-5 °C to 55 °C
-20 °C to 70 °C
IP40 / IP20
Check US distributor inventory
Accessories
Part number
110860133270
4251394620824
