LF-TI-IP65 LON
Description
The LON module in an IP65 housing with 4 universal inputs and 4 digital outputs was developed for decentralized switching tasks. It is suitable for detecting temperatures or voltages or for switching 4 thermal valve drives with triacs. The inputs and outputs are scanned and activated by SNVT network variables. The outputs can be operated either only switching or in clocking mode with adjustable pulse/pause ratio.
- Not intended for marketing in North America
Technical Data
General Data
TP/FT-10, free topology
FT5000
78 KBit/s
230 V AC, 50 Hz
less than 25 mA
100 %
4 x analog
40 Ohm to 4 MOhm
0 V to 10 V DC
10 mV (0 to 100%)
4 x digital, triac
20 V to 250 V AC
0.8 A
2.4 A / all outputs
2 A / output
Green and yellow LED
159 x 41.5 x 120 mm
330 g
-5 °C to +55 °C
-20 °C to +70 °C
IP65 / IP20
Check US distributor inventory
Accessories
Part number
11086105IP
4250184135838
Downloads
- Data sheet
- Brochure (LON I/O components)
- Brochure (Intelligent system components with integrated application software)
- 3D-Data - Registration required -
- Software (Template_LF-TI-IP)
- Software (LON Resource Files 1.32)
- Software (METZ Connect PlugIn LF-ALL 2.0.0)
- Mounting note (11086105IP LF-TI-IP)
- Mounting note (Safety Instructions multilingual )
- Software manual
