E-DAT C6A 24 port patch panel 0,5RU LSA
Description
- 19 inch 0.5RU frame made of black metal with 24 individually shielded RJ45 jacks
- Cat.6A component test according to ISO/IEC 11801, DIN EN 50173-1, ANSI/TIA-568.2-D and IEC 60603-7-51, GHMT certified
- compliance with class EA up to 500 MHz according to ISO/IEC 11801, DIN EN 50173-1
- tested: component up to 600 MHz, link up to 800 MHz
- suitable for 10 GBit Ethernet (IEEE 802.3an), Remote Powering (PoE, PoE plus, UPoE and 4PPoE) and HDBaseT
- wire pairs can be led to the LSA terminal block without untwisting the pair
- connection of 2 to 4 pair data cables to the LSA IDC terminal blocks (AWG 26/1 to 22/1). With color marking of the wires to T568A
- strain relief and shield tap by two separated cable brackets
Check US distributor inventory
Accessories
Part number
130854C-29-E
4250184195542
Downloads
- 3D-Data - Registration required -
- Mounting note
- Data sheet
