E-DAT C6 6 port 3RU 7HP LSA modular
Description
- 3RU/7HP 6-fold module housing made of zinc die-casting, mounting in 3RU module frame
- certified to GHMT Cat.6 12C-de-embedded
- compliance with class EA Channel-Link acc. to ISO/IEC 11801-1, DIN EN 50173-1
- tested: Channel-Link up to 500 MHz
- suitable for 10 GBit Ethernet (IEEE 802.3an), Remote Powering (PoE, PoE plus, UPoE and 4PPoE) and HDBaseT
- wire pairs can be led to the LSA terminal without untwisting the pair
- connection of 2 to 4-pair data lines to LSA insulation displacement connectors (AWG 22-24) conductor colors marking to TIA/EIA 568A
- 3RU module frame for mounting in surface-mounted housing, top hat rail adapter or 3RU module frame
- strain relief with captive cable clamp, Ø smaller then 8 mm (for cable Ø bigger then 7 mm see accessory)
- optional strain relief using cable ties
- label window for enclosed identification labels
- captive contact clamp for cable shield
- grounding bolt M6x10 with nut and lock washer
- suitable for xx GBit Ethernet (IEEE 802.3an), Remote Powering (PoE, PoE plus, UPoE and 4PPoE) and HDBaseT
Check US distributor inventory
Part number
130857-E
4250184116646
Downloads
- 3D-Data - Registration required -
- Certificate (GHMT Type Approval - E-DAT C6 24x8(8) - E-DAT C6 6 Port - Cat.6 Certificate)
- Mounting note
- Data sheet
