E-DAT C6A 6 port 3RU 7HP LSA modular
Description
- 3RU module, made of anodized aluminum, mounting in 3RU frame
- Cat.6A component test according to ISO/IEC 11801, DIN EN 50173-1, ANSI/TIA-568.2-D and IEC 60603-7-51, GHMT certified
- compliance with class EA up to 500 MHz according to ISO/IEC 11801, DIN EN 50173-1
- tested: components up to 600 MHz, link up to 800 MHz
- suitable for 10 GBit Ethernet (IEEE 802.3an), Remote Powering (PoE, PoE plus, UPoE and 4PPoE) and HDBaseT
- wire pairs can be led to the LSA terminal without untwisting the pair
- connection of 2 to 4-pair data lines to LSA insulation displacement connectors (AWG 26/1-22/1) conductor colors marking to T568A
- label window for enclosed identification labels
- optional strain relief using cable ties
- modules connected by means of grounding rail, incl. 30 cm grounding cable
- 3RU module frame for mounting in surface-mounted housing, top hat rail adapter or 3RU module frame
Check US distributor inventory
Part number
130857C-E
4250184118596
Downloads
- 3D-Data - Registration required -
- Certificate (GHMT Type Approval - E-DAT C6A 24x8(8) - E-DAT C6A 6 Port - Cat.6A Certificate)
- Mounting note
- Data sheet
