E-DAT C6 6x8 surface mounted distributor Cat.6, pure white
Description
- 6 port surface-mounted distributor or wall outlet for structured cabling in the building
- certified to GHMT Cat.6 12C-de-embedded
- compliance with class EA Channel-Link acc. to ISO/IEC 11801-1, DIN EN 50173-1
- tested: Channel-Link up to 500 MHz
- suitable for 10 GBit Ethernet (IEEE 802.3an), Remote Powering (PoE, PoE plus, UPoE and 4PPoE) and HDBaseT
- wire pairs can be led to the LSA terminal without untwisting the pair
- connection of 2 to 4-pair data lines to LSA insulation displacement connectors (AWG 22-24) conductor colors marking to TIA/EIA 568A
- label window for enclosed identification labels
- optional strain relief possible using cable ties
- variants: pure white, light gray
Check US distributor inventory
Part number
130862-21-E
4250184113294
