DCCS2 subassembly 6 port RJ45 - cross connect
Description
- cross connect subassembly 6 port RJ45 consisting of a solid stainless steel support and 6 couplers made of refined zinc die-casting
- for 6 patch cords on the front and on the back
- compliance with class EA up to 500 MHz according to ISO/IEC 11801, GHMT certified
- suitable for 10 GBit Ethernet (IEEE 802.3an), Remote Powering (PoE, PoE plus and UPoE) and HDBaseT
- Alien Next optimized, shielded jacks
- front side: the locking levers of the patch cords connected to the DCCS2 subassemblies all show upwards and allow easy handling at any time
- back side: the locking levers of the patch cords connected to the DCCS2 subassemblies all show upwards and allow easy handling at any time
- fastening and potential equalization in 19-inch subracks by a knurled screw
- easy mounting/dismounting to/from 19-inch subracks in 19-inch cabinets (plug and play)
- design: DCCS2
Check US distributor inventory
Accessories
Part number
130D2CMC6-E
4250184193838
