SM01W01VXNN05G1 13-inch Reel solder pad/component side

954939

Description

spring clamp terminal block, SMT solderable
one-way contact
direction of connection vertical 0°
Tape & Reel packaging

Technical Data

General Data

min. number of poles:

1

max. number of poles:

1

Protection category:

IP00

Insul. strip length:

4 mm

Rated current:

13 A

Connection Data

Connection capacity (single-wire):

0,1 - 0,75 mm²

Connection capacity (single-wire):

AWG 26 - 18

Connection capacity (multi-wire):

-

Connection capacity (multi-wire):

AWG -

Material

contact material:

CuBe

Contact surface:

Ni + Sn

Climatic Data

upper limit temperature:

150 °C

lower limit temperature:

-40 °C

Check US distributor inventory

Part number

Part number:

ASM01W0164-5G16

EAN:

4250184183990

Downloads

Buy article from our partners

Beyond Components

Digi-Key Electronics

Distrelec Deutschland GmbH

element 14, an Avent Community

Farnell, an Avnet Company

Future Electronics

Heilind Asia Pacific

Heilind Electronics America

Heilind Electronics Europe

INELTRO ELECTRONICS GmbH

Master Electronics

Newark, an Avnet Company

reichelt elektronik GmbH & Co. KG

TLC Electronics

Find contact person

Inquiry

Additional Information

Product family Spring clamp terminal blocks
